Garage Plan Ref 7050AHSR

7050AHSRCN
Add to cart
  • Description

7m x 5m Garage Plan with a Hipped roof - Rendered walls


7.6m x 5.6m Externally
35m² Ground Floor Area
12" Cavity wall construction
Single side door and window
9' x 7' Up and Over Garage Door
Truss rafter roof construction


17.5° roof pitch : Ridge Height = 3.6m
22.5° roof pitch : Ridge Height = 3.9m
30° roof pitch : Ridge Height = 4.3m
35° roof pitch : Ridge Height = 4.7m

This domestic two car garage is ideal for parking the family cars. With a wider interior than the standard double garage more room is available to open the car doors or moving around the car. The garage is wide enough to allow the DIY handyman to work around the car. The 9 feet wide garage door allows easy access to the garage. The cavity wall construction provides water proof construction.

WARNING!!! This is the smallest length of garage available. It will be adequate for most saloon type cars but will NOT be long enough for the larger type cars. If you have the building space available please select the 6m long garage. Check the length of your car here. car sizes
