Garage Plan Ref 3580AHSBCR
Garage Plan Ref 3580AHSBCR
3580AHSBCR
Add to cart
Description
More
3.5m x 8m Garage Plan with a Hipped roof - Brick walls and Rendered Corner Stones
3.7m x 8.45m Externally
28m² Ground Floor Area
4" side walls and 9" end walls
Single side door and two side windows
7' x 7' Up and Over Garage Door
Traditional rafter roof construction
17.5° roof pitch : Ridge Height = 3.3m
22.5° roof pitch : Ridge Height = 3.5m
30° roof pitch : Ridge Height = 3.8m
35° roof pitch : Ridge Height = 4m
The design of this domestic single car detached garage makes it ideal for parking the car. With a slightly longer and wider interior than the standard garage more room is available to open the car doors and provides additional storage or workshop space at the rear of the garage. The garage is constructed in 4 inch side walls to save on construction costs.
Links to 3D Images of garage design
3D image of 17.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Mineral Fibre Slates
3D image of 22.5º pitch roof - Natural Slates
3D image of 30º pitch roof - Concrete Interlocking Tiles
3D image of 30º pitch roof - Mineral Fibre Slates
3D image of 30º pitch roof - Natural Slates
3D image of 35º pitch roof - Concrete Interlocking Tiles
3D image of 35º pitch roof - Mineral Fibre Slates
3D image of 35º pitch roof - Natural Slates
3D image of 35º pitch roof - Clay/Concrete Plain Tiles
!
