8m x 8m
>
Single Storey 8080A
>
Garage Plan Ref 8080AHSRCB
Garage Plan Ref 8080AHSRCB
Garage Plan Ref 8080AHSRCB
8080AHSRCB
£
238.00
Roof Pitch and Finish
*
17.5° pitch roof - Concrete Interlocking Tiles
22.5° pitch roof - Concrete Interlocking Tiles
22.5° pitch roof - Mineral Fibre Slates
22.5° pitch roof - Natural Slates
30° pitch roof - Concrete Interlocking Tiles
30° pitch roof - Mineral Fibre Slates
30° pitch roof - Natural Slates
35° pitch roof - Concrete Interlocking Tiles
35° pitch roof - Mineral Fibre Slates
35° pitch roof - Natural Slates
35° pitch roof - Clay/Concrete Plain Tiles
Garage to be Mirrored
*
Not Mirrored
Mirrored
Drawing Package
*
By Email - pdf
pdf & 5 printed sets by Post
(
£25.00
)
Add to cart
Description
8m x 8m Garage Plan with a Hipped roof - Rendered walls and Brick Corner Stones
8.6m x 8.6m Externally
64m² Ground Floor Area
12" Cavity wall construction
Single side door and two side windows
9' x 7' Up and Over Garage Door and front window
Truss rafter roof construction
17.5° roof pitch : Ridge Height = 4.1m
22.5° roof pitch : Ridge Height = 4.5m
30° roof pitch : Ridge Height = 5.2m
35° roof pitch : Ridge Height = 5.7m
!
