3.5m x 10m
>
Garage Plan Ref 35100AHSRCB
Garage Plan Ref 35100AHSRCB
Garage Plan Ref 35100AHSRCB
35100AHSRCB
Add to cart
Description
More
3.5m x 10m Garage Plan with a Hipped roof - Rendered walls and Brick Corner Stones
3.95m x 10.45m Externally
35m² Ground Floor Area
9" wall construction
Single side door and three side windows
7' x 7' Up and Over Garage Door
Traditional rafter roof construction
17.5° roof pitch : Ridge Height = 3.3m
22.5° roof pitch : Ridge Height = 3.5m
30° roof pitch : Ridge Height = 3.9m
35° roof pitch : Ridge Height = 4.1m
This domestic detached garage is ideal for parking of two family cars. With a slightly longer and wider interior than the standard garage more room is available to open the car doors and provides additional storage or workshop space at the rear of the garage. Constructed with 9 inch walls all round to give better weather protection. This garage is suitable for narrow but long building sites.
Links to 3D Images of garage design
3D image of 17.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Mineral Fibre Slates
3D image of 22.5º pitch roof - Natural Slates
3D image of 30º pitch roof - Concrete Interlocking Tiles
3D image of 30º pitch roof - Mineral Fibre Slates
3D image of 30º pitch roof - Natural Slates
3D image of 35º pitch roof - Concrete Interlocking Tiles
3D image of 35º pitch roof - Mineral Fibre Slates
3D image of 35º pitch roof - Natural Slates
3D image of 35º pitch roof - Clay/Concrete Plain Tiles
!
