8m x 5m
>
Single Storey 8050B
>
Garage Plan Ref 8050BBSRCB
Garage Plan Ref 8050BBSRCB
Garage Plan Ref 8050BBSRCB
8050BBSRCB
Add to cart
Description
More
8m x 5m Garage Plan with a Pitch roof - Rendered walls and Brick Corner Stones Gable Sided Roof- style B
8.6m x 5.6m Externally
40m² Ground Floor Area
12" Cavity wall construction
Single side door and window
2No 6'-6" x 6'-6" Up and Over Garage Doors and front window
Truss rafter roof construction
17.5° roof pitch : Ridge Height = 3.6m
22.5° roof pitch : Ridge Height = 3.9m
30° roof pitch : Ridge Height = 4.3m
35° roof pitch : Ridge Height = 4.7m
WARNING!!!
This is the smallest length of garage available. It will be adequate for most saloon type cars but will
NOT
be long enough for the larger type cars. If you have the building space available please select the 6m long garage. Check the length of your car
here.
