Garage Plan Ref 3070ALSRCB
Garage Plan Ref 3070ALSRCB
3070ALSRCB
Add to cart
Description
More
3m x 7m Garage Plan with a Pitch roof - Rendered walls and Brick Corner Stones Gable Fronted Roof
3.2m x 7.45m Externally
21m² Ground Floor Area
4" side walls and 9" end walls
Single side door and window
7' x 7' Up and Over Garage Door
Traditional rafter roof construction
17.5° roof pitch : Ridge Height = 3.2m
22.5° roof pitch : Ridge Height = 3.4m
30° roof pitch : Ridge Height = 3.6m
35° roof pitch : Ridge Height = 3.8m
The design of this domestic single car detached garage makes it ideal for parking the car. This garage is slightly longer than the standard garage and allows for some additional storage space. The garage is constructed in 4 inch side walls to save on construction costs.
Links to 3D Images of garage design
3D image of 17.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Concrete Interlocking Tiles
3D image of 22.5º pitch roof - Mineral Fibre Slates
3D image of 22.5º pitch roof - Natural Slates
3D image of 30º pitch roof - Concrete Interlocking Tiles
3D image of 30º pitch roof - Mineral Fibre Slates
3D image of 30º pitch roof - Natural Slates
3D image of 35º pitch roof - Concrete Interlocking Tiles
3D image of 35º pitch roof - Mineral Fibre Slates
3D image of 35º pitch roof - Natural Slates
3D image of 35º pitch roof - Clay/Concrete Plain Tiles
!
